Leaving behind Anglo-Saxon England, there are currently no R-CTS12023/R-DF95 ancient DNA results to look at and compare. It’s as if we popped up in England even though the results of the recent Anglo-Saxon DNA study clearly show an affinity for the continental North Sea and Baltic world. From here on out, we are back to chasing shadows. We know we’re in there…just not so sure where.

Rough Contemporaries from the European Continent

These are men from 200 CE to nearly 1100 CE that were included in the results and comparisons for the Anglo-Saxon migration study. I think we could call it Medieval DNA. 200 CE is roughly when Family Tree DNA expects R-ZP121 to have originated (Before the Fall of Rome). For this set, I attempted to remove all the English Y DNA results. That leaves us with Denmark, Germany, Ireland, and the Netherlands. Sweden is conspicuously absent.

For these comparisons, I’m using a copy of this spreadsheet that was shared on Anthrogenica, where the community was working on and discussing the ancient DNA results. This spreadsheet appeared to inform some corrections of early results listed in the U106 ancient DNA spreadsheet. Here again, I benefit from the labor and ingenuity of others.

Right off the bat, then, there are some things to be aware of.

These results are from this particular study but don’t constitute all the results used in the study. They also used DNA from many more locations and other studies for comparison. What that means is this is a subset of the data they used for comparisons.

Because we’re pulling Y DNA results out of a regional Autosomal DNA study, at least half the population is missing, and some locations where only females were sampled are entirely gone from my results list.

Lower Saxony and the Netherlands

This is an arbitrary breakout of the results from Lower Saxony, with Groningen thrown in because of proximity. Because I’m ignorant of geographical and cultural significance, I wouldn’t put too much weight behind this grouping. There are 72 Y DNA results from these locations:

• Inden, Germany (16 results)
• Liebenau, Germany (5)
• Drantum, Germany (5)
• Anderten, Hanover, Germany (11)
• Hiddestorf, Germany (4)
• Schortens, Germany (4)
• Groningen, Netherlands (12)
• Dunum, Germany (13)
• Zetel, Germany (1)
• Issendorf, Germany (1)

There is an inequity in results. Coverage is not evenly distributed. Some of the male Y DNA just couldn’t be read, and some of it couldn’t be read to a meaningful conclusion. It’s also true, like my last post, that these results may be nested with one person stopping higher up the Y tree than we would like and another getting a more meaningful call at a lower branch. When I’m listing countries for these, there are often many, but I’m only listing the top few from FTDNA, and I’m leaving out the U.S.

Haplogroup E

There is one sample in E-BY152493; there are 12 modern testers from England, Germany, Italy and Belarus.

Haplogroup G

There are three G samples from G-P303 (3582 modern testers, mainly from England and Germany), G-U1 (701 testers mainly from Russia, Germany, and England), and G-S23438 (97 testers, mainly from England and Germany).

Haplogroup J

There are four haplogroup J samples. Two are from J-Z1043 (418 modern from Germany, Russia, and England), and two are from J-Y12007 (65 modern, Russia, and England).

Haplogroup I

There are 15 total Haplogroup I samples. Described as Europe’s native son, it’s no slouch in these results.

• I-P222 – 10,000 BCE, 5323 modern testers from England and Ireland.
• I-Y37834 – 1350 BCE, 49 testers from England, Ireland and Scotland.
• I-BY200839 – 550 CE, 3 testers from Germany and England.
• I-FGC6800 – 1000 BCE, 45 testers from Poland and England.
• I-S21825 15000 BCE, 561 testers from England and Scotland.
• I-Y4197 150 BCE, 350 testers from England and Scotland.
• I-A6181 – This one seems to have had issues. 2000 CE, 2 testers from Finland. This is a family level SNP currently so it would be really interesting if it was also found in 600 CE in Inden Germany.
• I-CTS10028 – (2 samples) 2100 BCE, 5372 testers from Finland, Sweden, and England.
• I-Y13121 – 1400 BCE, 39 testers from England and Russia.
• I-BY70642 – 950 CE, 3 testers from Sweden.
• I-Y5834 – 250 BCE, 39 testers from Norway, England and Sweden.
• I-FT258257 – this one is also a bit suspect, estimated at 1850 CE with 2 testers. The sample is from issendorf circa 400 CE.
• I-Z141 – 1950 BCE, 2373 testers from England and Germany.
• I-Z63 – 2300 BCE, 1598 testers from England and Germany.

A couple of observations:

Age estimates are only estimated so some of those suspect calls for recent haplogroups could be bad calls or they could be estimates with too little information to go on. If two people related in the 1800s are the only ones on a branch with a thousand years worth of SNPs it would be hard to guess where any one SNP fell in the timeline without Ancient DNA like this.

Some of these haplogroup I branches have 90 plus countries under them so some of my listings that say something like “England and Russia” for 2000 testers is a gross understatement of how widespread that group is.

Haplogroup R

Haplogroup R for the win again here. Just as with modern testing in Western Europe, R is popular. I’m going to break it down into some component parts. Also since R is my haplogroup I’m biased, and it will show.

R1a

• R-YP1051 – 800 BCE, 23 testers from Germany, Switzerland and the U.K. Sample was from Alt-Inden, Germany 600 CE.
• R-M417 – 3400 BCE, 13266 testers from Poland, Russia and Germany. Sample was from Schortens, Lower Saxony, Germany 800 CE.
• R-YP1258 – 550 BCE, 84 testers from Norway, England and Scotland. Sample was from Drantum, Lower Saxony, Germany 831 CE.

R1b-M269+

At these base R1b levels with 70 or 80 thousand testers, the country lists here can’t be taken seriously. For example, R-L151 is in 124 countries. The countries for haplogroups with several hundred testers are much more informative.

• R-M269 – 4350 BCE, 85,215 testers from Ireland and England This is the big base group for R1b. The sample was taken from Zetel, Lower Saxony, Germany 735 CE.
• R-CTS9219 – 2250 BCE, 712 testers from Germany, Czech Republic and Ireland. Sample from Alt-Inden, North Rhine-Westphalia, Germany 600 CE.
• R-FGC48821 – 2850 BCE, 205 testers from Germany and Scotland. Sample taken from Groningen, Groningen, Netherlands 875 CE.
• R-L151 – 3000 BCE, 74,779 testers from Ireland and England. Sample taken from Dunum, Lower Saxony, Germany 938 CE.
• R-S6849 – 700 BCE, 13 testers from Norway and England. Sample from Alt-Inden, North Rhine-Westphalia, Germany 600 CE.

R1b-P312+

R-P312 is a very large branch of R1b. There are 15 R-P312+ results in the set, but 4 of them were left at just the major branch R-P312. Like being left are R-M269 this will skew the results of any country count or amount of testers.

• R-P312 – 2800 BCE, 53,057 modern testers from Ireland, England and Scotland. These samples were from Alt-Inden, Westphalia, and Dunum, Lower Saxony from 600 to 829 CE.
• R-Z39292 – 1400 BCE, 6 modern testers from Italy, Norway, and the U.K. Sample was from Alt-Inden, North Rhine-Westphalia, Germany 600 CE.
• R-DF88 – 2100 BCE, 824 testers from Germany, Scotland and England. Sample from Hiddestorf, Lower Saxony, Germany 400 CE.
• R-S4281 – 1600 BCE, 708 testers from Germany and England. Sample from Hiddestorf, Lower Saxony, Germany 400 CE.
• R-DF13 – 2450 BCE, 26,412 testers from Ireland and Scotland. Sample from Alt-Inden, North Rhine-Westphalia, Germany 600 CE.
• R-S5488 – 2100 BCE, 629 testers from Ireland and Scotland. Sample from Alt-Inden, North Rhine-Westphalia, Germany 600 CE.
• R-FT185253 – 450 BCE, 2 modern testers from France and Sweden. Sample from Groningen, Groningen, Netherlands, 1070 CE.
• R-BY41129 – 700 BCE, 6 testers from France, Scotland, Ireland and U.K. Sample from Groningen, Groningen, Netherlands 1040 CE.
• R-Z258 – 2400 BCE, 1,285 testers from England and France. Sample from Alt-Inden, North Rhine-Westphalia, Germany 600 CE.
• R-BY13147 – 1200 BCE, 25 testers from Belarus, Lithuania and Germany. Sample from Alt-Inden, North Rhine-Westphalia, Germany 600 CE.
• R-FGC22963 – 2100 BCE, 83 testers from England and Northern Ireland. Sample from Hannover-Anderten, Lower Saxony, Germany 750 CE.
• R-Z258 – 2400 BCE, 1,285 testers from England and France. Sample from Hannover-Anderten, Lower Saxony, Germany 750 CE.

R1b-U106+

There are 18 samples from R-U106 of those 8 are under R-L48 a major group of R-U106 and 2 are under R-Z18.

• R-S19552 – 560 BCE, 14 testers from England, Ireland and Germany. Sample was from Hiddestorf, Lower Saxony, Germany 479 CE.
• R-BY116631 – 800 BCE, 2 testers from unknown countries. Sample was from Hiddestorf, Lower Saxony, Germany 480 CE.
• R-S1855* – 1800 BCE, 84 testers from England and France. Sample from Groningen, Groningen, Netherlands 908 CE.
• R-Z381 – 2650 BCE, 14,657 testers from England and Germany. A major parent group in U106. Sample was from Dunum, Lower Saxony, Germany 800 CE.
• R-Z304 (2 samples) – 2150 BCE, 2,061 testers from England and Germany. Samples from Dunum, Lower Saxony, Germany 800 CE, and Schortens, Lower Saxony, Germany 792 CE.
• R-Z159 – 1700 BCE, 1,064 testers from England and Germany. Sample was from Groningen, Groningen, Netherlands 730 CE.
• R-S21607 – 200 CE, 60 testers from Finland, Scotland, and England. Sample was from Groningen, Groningen, Netherlands 883 CE.
• R-BY18737 – 600 BCE, 22 testers from Ireland, England, and Northern Ireland. Sample from Schortens, Lower Saxony, Germany 781 CE.
• R-S23955 – 950 BCE, 252 testers from Germany and England. Sample from Hannover-Anderten, Lower Saxony, Germany 750 CE.
• R-S15823 – 200 BCE, 12 testers from England, Norway, and Germany. Sample from Groningen, Groningen, Netherlands 1100 CE.
• R-CTS10893 – 800 BCE, 587 testers from England and Scotland. Sample from Hannover-Anderten, Lower Saxony, Germany 750 CE.
• R-Z8 (2 samples) – 950 BCE, 2,669 testers from England and the U.K. Samples from Drantum, Lower Saxony, Germany, and Hannover-Anderten, Lower Saxony, Germany 750 CE.
• R-Z153 – 1050 BCE, 110 testers from Ireland and England. Sample from Dunum, Lower Saxony, Germany 800 CE.
• R-S16361 – 250 BCE, 57 testers from Scotland, England, and the Netherlands. Sample from Groningen, Groningen, Netherlands 1013 CE.
• R-S17721 – 200 CE, 29 testers from England, the Netherlands and Scotland. Sample from Groningen, Groningen, Netherlands 1008 CE.
• R-S11880 – 750 CE, 4 testers from Sweden. Sample from Dunum, Lower Saxony, Germany 723 CE. Interesting because the group is so small, and the estimated age is so close to the age of the sample.

There are some really small haplogroups in here, which is really interesting, and a broad range of estimated ages. The last two in the list are the R-Z18 samples. The R-L48 samples overpower all the others, but L-48 breaks down into some pretty small groups of modern testers as well.

Northern Germany and Denmark

Again an arbitrary breakout of results from Denmark and Northern Germany. There are 25 results, three of them could not be read well, and so I’m leaving them out.

Results from:

• Häven, Mecklenburg-Vorpommern, Germany (9)
• Schleswig Rathausmarkt, Schleswig-Holstein, Germany (13)
• Sct. Clements, Copenhagen, Zealand, Denmark (3)

Haplogroup G

One sample in G-Z727 which formed around 2450 BCE and has 1,451 modern testers from Germany and England.

Haplogroup I

8 Results from I. All these results are from Schleswig Rathausmarkt, Schleswig-Holstein, Germany and Häven, Mecklenburg-Vorpommern, Germany from 300 CE to 1140 CE.

• I-FT352054 – 1750 CE, 2 modern testers from Finland and Latvia.
• I-M253 – 2550 BCE, 24,922 modern testers from England, Sweden and Germany.
• I-Y15300 – 1650 CE, 55 modern testers, most from the U.S. with 1 Belgium and on England. This sample was found in 300 CE. The parent haplogroup for this one is estimated at 500 CE so I would expect these estimates to shift with this result.
• I-CTS9889 – 500 CE, 13 testers, England, Ireland, and Scotland.
• I-BY244 – 800 CE, 9 testers from Sweden and Poland.
• I-Y5384 – 250 BCE, 93 testers from Sweden and Denmark.
• I-FT111982 – 1900 CE, 2 testers from Denmark. This sample is from 1140 CE in Schleswig-Holstein. Again probably a lot of SNPs in a straight line here down to 2 testers so I expect this age estimate to adjust.
• I-Y21381 – 350 CE, 12 testers from England, Ireland and U.K.

Haplogroup R

There are 13 results from Haplogroup R.

R1a

• R-CTS4179 – 500 BCE, 1,037 modern testers from Scotland, Norway and Sweden. Sample from Sct. Clements, Copenhagen, Zealand, Denmark 1150 CE.

R1b-M269+

These results near the base of R-M269 will be almost non-sensical for country data.

• R-L51 – 4000 BCE, 75,328 testers mainly from Ireland and England. Sample from Schleswig Rathausmarkt, Schleswig-Holstein, Germany 1105 CE.
• R-P311 – 3300 BCE, 74,817 testers, from Ireland and England. Sample from Schleswig Rathausmarkt, Schleswig-Holstein, Germany 1105 CE.
• R-L151 – 3000 BCE, 74,779 testers from Ireland and England. Sample from Häven, Mecklenburg-Vorpommern, Germany 300 CE.

R1b-P312+

• R-FT271169 – 1250 BCE, 2 testers from France and Scotland. Sample from Schleswig Rathausmarkt, Schleswig-Holstein, Germany 1140 CE.
• R-FT202151 – 550 BCE, 7 testers from England and the Netherlands. Sample from Schleswig Rathausmarkt, Schleswig-Holstein, Germany 1105 CE.

R1b-U106+

There are 3 R-L48 results, and the last 2 are R-Z18.

• R-U106 – 2950 BCE, 18,876 from England and Germany. Sample from Häven, Mecklenburg-Vorpommern, Germany 300 CE.
• R-S15627 – 1300 BCE, 588 testers from England and Scotland. Sample from Häven, Mecklenburg-Vorpommern, Germany 300 CE
• R-FGC17304 – 200 BCE, 53 testers from Poland and England. Sample from Häven, Mecklenburg-Vorpommern, Germany 300 CE
• R-BY41837 – Sample from Schleswig Rathausmarkt, Schleswig-Holstein, Germany 1105 CE
• R-Z8175 – 650 CE, 2 testers from Estonia. Sample from Schleswig Rathausmarkt, Schleswig-Holstein, Germany 1175 CE
• R-BY18896 – 1350 BCE, 4 testers from the Czech Republic, Denmark and the U.K. Sample from Häven, Mecklenburg-Vorpommern, Germany 300 CE
• R-S17721 – 200 CE, 29 testers from England, the Netherlands, and Scotland. Sample from Schleswig Rathausmarkt, Schleswig-Holstein, Germany 1140 CE

I’m going to admit that I’m surprised to see the R-U106 samples outnumber the R-P312 testers in these two arbitrary regions I’ve listed out. These are small amounts of samples, but still, I expected a better showing from R-P312, which is a legitimate monster in the R1b world.

The Irish

in these samples are also tests from 950 CE Kilteasheen, The Bishop’s Seat, Roscommon, Ireland, meant to be a genetic foil, I believe, to the Anglo-Saxons buried in England. They represent the WBI in the study. In that group, there was 1 haplogroup I result (which kind of surprised me, I expected more) and then 27 R-P312 results…which is not surprising. Most were under R-L21, which is a major group of R-P312 and really common in the Isles. I looked for R-U106 results, and there were none.

Conclusions

What I find satisfying about these results is that they are ancient results. Most of the time we have had to make guesses about ancient movements based on the locations of modern testers. We have had to speculate without having all the information. Here we have some concrete ancient DNA to work with. Even if the outcome is what we expected based on the locations of modern testers and their genealogical connections, the ancient DNA serves as an anchor point for those expectations.

Looking at Continental Northern Europeans

Haplogroup I has 41,069 modern testers. Haplogroup R has 105,925, more than twice as many testers. Haplogroup I in this study (from Continental Northern Europe) has 23 samples. Haplogroup R has 55 samples. Again, more than twice as many. It seems like these results are what you would broadly expect in Europe. Most of the I results were down the I-M253 branch. It appears that Haplogroup I beat Haplogroup R to Europe by thousands of years.

Haplogroup G has 9,515 modern testers. Haplogroup R has 11 times as many. Haplogroup G in this study has 4 results to Haplogroup R’s 55. R is roughly 14 times larger. I would guess by the results that Haplogroup G’s center of influence is farther away and the map from SNP tracker seems to back that up. Of Note, Otzi the Iceman is a member of Haplogroup G. He was found in the Alps between Austria and Italy. By 3350 BCE there were haplogroup G men in the Alps.

Haplogroup J has 34,542 modern testers. R is about 3 times as large. In this study, there are 4 haplogroup J results. R is roughly 14 times larger than J here. I’d suspect Haplogroup J results have an interesting migration story, although it seems like their route was more straight forward than R. Haplogroup J men are found in Croatia circa 2000 BCE.

Haplogroup E has 20,154 modern testers; there are roughly 5 times as many R results in the world. Haplogroup E in this study has only 1 result. R is 55 times larger. Haplogroup E seems pretty strikingly rare in Medieval northern Germany. Haplogroup E was found in ancient remains from Spain circa 2400 BCE.

Haplogroup R is the invader from the east, moving into Europe and becoming the largest haplogroup in Western Europe, reaching something like 90% in Ireland. We came the long way around, and we clumped up there when we hit the British Isles.

R1a represented by R-M198 branch (in Eastern Europe) in the map below has 5 results among these samples, but 16,599 modern testers. It’s about 16% of modern R, but 9% of R in this study.

R-P312 is roughly 50% of modern R. In this study they have 17 results, about 31%. This is a significant decrease that seems to have been taken up by R-U106.

R-U106 is roughly 18% of modern Haplogroup R (in Central Europe on the map below). In this continental northern European study it has 25 out of 55 R results. Very nearly 50% of Haplogroup R and slightly larger than Haplogroup I. R-U106 outnumbers R-P312 (in Western Europe in the map below) in these ancient results (once we exclude the Irish results). This is a good turnout for R-U106.

Treating subgroups of R like major haplogroup breaks and focusing on my own home groups: R-U106 has 25 results out of 97. About a quarter of this…uneven…population transect. More than I and J etc, but a quarter of the whole, and that is a good turnout for R-U106. I believe the U106 population declines the further south and east you go. That plays out in the locational data. R-U106 doesn’t appear in the graves for Inden, Germany, the southernmost location. R-P312 is the king there.

If I remove the places where R-U106 doesn’t exist the map looks like this:

In order of the number of samples with U106:

• Groningen, Groningen, Netherlands (6 of 12)
• Häven, Mecklenburg-Vorpommern, Germany (5 of 9)
• Dunum, Lower Saxony, Germany (4 of 13)
• Schleswig Rathausmarkt, Schleswig-Holstein, Germany (4 of 13)
• Hannover-Anderten, Lower Saxony, Germany (3 of 11)
• Hiddestorf, Lower Saxony, Germany (2 of 4)
• Schortens, Lower Saxony, Germany (2 of 4)
• Drantum, Lower Saxony, Germany (1 of 5)

R-U106 -> R-Z18

This is about as close as we’re going to get to R-CTS12023/DF95. Our major branch is R-Z18 before you have to hop back to meet others in R-U106. The R-Z18 results above would be related to us around 2200 BCE. All the results on the continent were down a larger R-Z18 branch, R-Z17.

Of the 97 results from the continent, 4 of them were R-Z18. In this transect of probable Anglo-Saxon origins, R-Z18 makes up about 4% of the available population. Since R-Z18 is about 1% of the modern testers from haplogroups represented here (E, G, I, J, and R), that is interesting. It would seem reasonable that you’re more likely to find R-Z18 in this zone.

R-Z18 is about 12% of R-U106 and 16% of R-U106 in this study. Just ever so slightly higher.

For comparison, R-L48 is about 47% of R-U106. In this study, it’s sitting at about 44% of U106 results. Just ever so slightly lower..but still the king.

R-Z18 has one each in Groningen, Häven, Dunum and Schleswig. Probably not surprising to see it in areas where there are more R-U106 to be found and maybe hugging the coast a bit tighter than others in U106.

Here’s a map of the continental R-Z18 world as defined by this study.

CTS12023 is 6.7% of R-Z18 and 0.07% of the modern testers from Haplogroups represented in the study. The likelihood of finding us here does seem better than some of the groups that only have 2 modern testers! The odds get less likely for R-ZP121 downstream from CTS12023, I would think, but still better than the micro-groups. We appear to be more likely to be found in medieval coastal northern Europe.

The oldest R-Z18 sample in this study was from 300 CE in Häven.

Questions

There are 97 Results, excluding the Irish. There are 3 Y DNA results from Denmark. 12 Y DNA results from the Netherlands and 82 from Germany.

A question I’m left with is If this study, with its better genetic coverage, had branched out into northern Denmark, Norway, and Sweden or further down into the Netherlands and Belgium, would they have struck some CTS12023 results as they did in Anglo-Saxon England? Are we resting somewhere between these cemeteries? Are there more medieval cemetery digs in the vicinity that could be mined for DNA?
